Description

Key Features:

• Wide Input Voltage Range: Operates efficiently within a voltage range of 110–300Vac, accommodating unstable power conditions.

• High Power Factor: An input power factor of 1.0 with Power Factor Correction (PFC) enhances energy efficiency and reduces electricity costs.

• Selectable Output Voltage: Offers flexibility with output voltage options of 208/220/230/240Vac to suit various regional requirements.

• Emergency Power Off (EPO): Equipped with an EPO function for immediate shutdown during emergencies, ensuring safety.

• ECO Mode Operation: An energy-saving mode that improves efficiency during periods of low load.

• Intelligent Fan Speed Regulation: Adjusts fan speed based on load and temperature, minimizing noise and extending component life.

• Comprehensive Protection: Safeguards against short-circuit, overload, overheat, battery overcharge and over-discharge, output low voltage, and fan faults.

• Multiple Communication Interfaces: Standard RS232 interface with optional USB, EPO, Relay card, and SNMP card for versatile monitoring and management.

Technical Specifications:

• Model: PS-POU2K#4B9KR

• Capacity: 2000VA / 2000W

• Input Voltage Range: 110–300Vac

• Input Frequency: 40–70Hz

• Output Voltage: 208/220/230/240Vac (selectable)

• Output Frequency: 50/60Hz ± 0.25Hz (battery mode)

• Voltage Regulation: ±1%

• Waveform: Pure sine wave

• Transfer Time: Zero ms (AC to battery), 4 ms (inverter to bypass)

• Battery Type: 4 x 12V/9Ah sealed lead-acid batteries

• Charging Time: <5 hours to 90% capacity

• Dimensions (W x D x H): 145 x 397 x 220 mm

• Net Weight: Approximately 17 kg

• Operating Temperature: 0–40°C

• Humidity: 20–90% RH (non-condensing)

• Noise Level: <50 dB at 1 meter

• Certifications: CE, RoHS

• Warranty: 4 years for UPS, 2 years for batteries
